Precision Automotive Tool For Die Maintenance And Alignment

The tool features calibrated guide pins and interchangeable tip sets that match common die shoe sizes. Instead of tapping components with a hammer, technicians use the guided insertion method to keep everything square. This protects both the tool and the expensive die blocks.

We've added ergonomic grips and a lightweight alloy body to reduce fatigue during long shifts. When a stamping line goes down for a die change, every minute counts. With this tool, locating pins and bushings slip into place faster and with less effort.

Related Links

This automotive tool isn't limited to large panel dies. It also works for smaller brackets and reinforcement dies. Having one reliable alignment tool across your tool room simplifies training and ensures every technician follows the same clean assembly procedure. It comes in a custom-fitted case for organized storage.
