Stainless Steel Sink Deep Drawing Die

Product Details:
Engineered for the demanding deep drawing of large, flat sinks with tight corner radii, this stainless steel sink deep drawing die uses hydraulic cushion force control to prevent material wrinkling during the entire stroke. The first draw creates the bowl, followed by redrawing and ironing stages that refine the shape and smooth the surface. The die can accommodate single-bowl, double-bowl, and farmhouse style sink designs.

The punch and die inserts are made from alloyed ductile iron or high-carbon high-chromium tool steel, with working surfaces polished to Ra 0.05μm and treated with a TD (Thermal Diffusion) or PVD CrN coating. These coatings dramatically reduce galling when drawing stainless steel. Internally cooled punches maintain a stable operating temperature, preventing material adhesion and extending tool life.

We deliver the complete die set matched to your hydraulic press parameters. Each stainless steel sink deep drawing die is fully tested with 304 stainless steel sheet, producing sample sinks that are checked for wall thickness distribution and surface finish. This tooling solution provides a competitive edge for sanitary ware manufacturers seeking high-quality, blemish-free products.
