Door Lock Strike Plate Stamping Die

Product Details:
This door lock strike plate stamping die is engineered to punch the complex center slot, screw holes, and outer profile of a strike plate in a single stroke. The compound die arrangement ensures excellent concentricity between the central opening and mounting holes. A positive knockout system prevents part sticking and maintains flatness, which is critical for the part's function in door locking mechanisms.

The die set uses a high-precision steel frame with four-post guidance. Cutting punches and die plates are made from DC53 or powdered metallurgy high-speed steel, vacuum heat-treated for high toughness and wear resistance. Edges are sharpened by wire-cut EDM and surface-treated to reduce friction. All components of the door lock strike plate stamping die are interchangeable, allowing for quick repair and regrinding.

Suitable for standard ANSI, DIN, and custom lock strike plates in materials like cold-rolled steel, stainless steel, or brass. We accept samples or drawings for die customization. Every door lock strike plate stamping die we ship has been fully tested to produce parts that meet strict flatness and dimensional requirements for the architectural hardware industry.
