Transfer Stamping Die For Deep Drawn Motor Housing

Product Details:

Mechanical Integration & Fingers: The die set is designed to work seamlessly with the press transfer system. Each station has defined gripping zones and part presence sensors. Cam‑driven lifters and funnel locators ensure the housing is precisely positioned even at high transfer speeds, eliminating mis‑feed and die crashes.

Part Orientation & Anti‑Rotation: During transfer, the part is held in perfect orientation by mechanical fingers that register on embossed features. We simulate the entire transfer pitch and lift trajectory using dynamic software to avoid interference. A bead‑control system in the draw die prevents the part edge from rotating.

Maintainability & Tool Life: Segmented punches and die inserts allow rapid replacement of wear components without dismounting the entire die. The upper turret uses quick‑change retainers. We deliver a detailed parts list, spare punch kit, and a scheduled preventive maintenance calendar. Die life exceeds 800,000 cycles before major refurbishment.
