I. Importance of Microstructure Die Design for Ultra-Thin Parts

Ultra-thin parts, with a thickness of 0.01-0.1mm, have low toughness, are easily deformed, and prone to breakage. The stamping process demands extremely high precision and stability from the dies. Microstructure dies must simultaneously meet requirements for wear resistance and rigidity, and the dimensional tolerances of the microstructures must be controlled within ±0.5μm. Precise control of the micro-geometric dimensions during stamping is crucial to prevent wrinkles, breakage, and dimensional errors in ultra-thin parts, directly impacting product performance and production efficiency.

II. Design Concept and Key Technologies

1. Refined Design Concept: Utilizing 3D digital design software to model the die's microstructure, and employing finite element analysis (FEA) to simulate material stress distribution during stamping, optimizes the die's microstructure dimensions and stamping parameters. This reduces the risk of material deformation and stress concentration, ensuring a die lifespan of ≥500,000 cycles and a stamped part qualification rate of ≥99.5%.

2. Material Selection and Surface Treatment: The mold is made of ultra-fine grain mold steel and powder metallurgy high-speed steel (such as ASP 23), which undergoes vacuum quenching and deep cryogenic treatment to achieve a hardness of HRC62-65, ensuring the mold's rigidity and wear resistance. The surface is treated with ion nitriding or TiN titanium plating, with a nitriding layer thickness of 0.1-0.2mm and a titanium plating layer thickness of 0.005-0.01mm, improving the mold's wear and corrosion resistance and preventing scratches and sticking during stamping.

3. Application of Micro-machining Technology: Five-axis CNC milling machines, precision EDM, and laser micro-machining equipment are used to achieve micro-structure machining of the mold. Machining accuracy is controlled within ±0.3μm, ensuring the consistency and integrity of micro-structure dimensions and adapting to the micro-structure forming requirements of ultra-thin parts.

4. Innovative Die Structure: Utilizing a modular design, the microstructure forming module, guiding module, and pressing module are separated. The module interface positioning accuracy is ≤0.003mm, allowing for quick module replacement and adaptability to the production of ultra-thin parts of different specifications, thus improving production flexibility. The die is equipped with vibration and temperature sensors, connected to an intelligent monitoring system, to collect stamping process data in real time, enabling automatic alarms for abnormal situations and real-time parameter adjustments, thereby enhancing the level of automation and intelligence in production.
