I. Machine Tool Coordinate System: The "Reference Coordinate System" for Machining
The machine tool coordinate system is the most fundamental and core coordinate system in machining. Its definition strictly follows international standards, with the core principle being "tool movement relative to a stationary workpiece." Through unified coordinate axis directions and origin settings, it provides a reference framework for machine tool movement.

Logically, the machine tool coordinate system uses a right-handed Cartesian coordinate system. The Z-axis is the direction of the machine tool spindle axis, with its positive direction pointing away from the workpiece, ensuring a clear and controllable relative position between the tool and the workpiece. The X-axis is perpendicular to the Z-axis, located within the workpiece clamping plane, and parallel to the radial direction of the workpiece, with its positive direction also following the principle of moving away from the workpiece. The Y-axis is determined by the right-hand rule, forming a complete three-dimensional coordinate system with the X and Z axes. The origin of the machine tool coordinate system, also known as the machine tool origin, is a fixed point set by the machine tool manufacturer. It is typically located at the positive limit positions of each coordinate axis of the machine tool. This origin serves as the reference for all motion coordinates of the machine tool. Regardless of how the workpiece is clamped, the machine tool's motion commands are all referenced to this origin, fundamentally ensuring the consistency of machining coordinates.

In machining practice, the definition of the machine tool coordinate system directly determines the machine tool's motion accuracy. When the operator starts the machine tool, it automatically returns to the machine tool origin, completing the coordinate reference calibration. All subsequent tool movements and workpiece feeds are essentially performed under the machine tool coordinate system, based on the defined coordinate axis directions and the origin, executing precise position control. This confirms the core position of the machine tool coordinate system as the machining reference; its rigorous definition is a prerequisite for achieving high-precision machining.

II. Workpiece Coordinate System: A "Dedicated Coordinate System" Fitted to Machining Needs

If the machine tool coordinate system is the global reference, then the workpiece coordinate system is a "customized coordinate system" for a specific workpiece. Its core definition lies in establishing a coordinate system with the workpiece as the reference, based on the workpiece's clamping position and machining characteristics, making machining instructions more closely aligned with actual operational needs.

The key to defining the workpiece coordinate system is the setting of its origin. This origin is called the workpiece origin or programming origin, and is usually determined by the programmer based on the workpiece's geometric characteristics, clamping method, and machining convenience. For example, when machining shaft parts, the workpiece origin is often set at the center of the shaft's end face; when machining plate parts, it is often set at a corner point or center of symmetry. The coordinate axes of the workpiece coordinate system are consistent with the machine tool coordinate system, following the right-hand Cartesian coordinate system rules, but the position of the origin can be adjusted according to the actual workpiece. This flexibility allows the workpiece coordinate system to accurately adapt to the machining needs of different workpieces, avoiding the hassle of repeatedly modifying the program due to different workpiece clamping positions.
