Non-standard coal mine tray mold
High precision stamping quality supplier
Composition and working characteristics of bolt tray mould for Mine:
Mine bolt tray die (300x300 tray, 150x150 anchor tray), also known as bolt tray stamping die, is divided into the upper part and the lower part. In the upper half, the sliders of the press and the support are connected to each other, and the support and connection are connected by setting screws. At the same time, working parts, working parts A and B constitute a unified whole. The lower surface is the working surface, the shape of the working surface is roughly the same as that of the tray, and it is processed in accordance with the form of kilogram ah technology. Drill holes in the center of the work piece to install the drill bit.
In the lower part of the bolt tray mold, the press and the support part are connected to each other, and the working part includes two parts, A and B, and A shall be placed on the upper part of B. Under the action of the screw, the working part and the support part are connected. Here, the screws mainly play a fixed role to ensure that the horizontal direction will not move, and control the movement of the upper and lower parts within the technical range.
Performance advantages of mine bolt tray mould:
1. The mould of mine bolt tray is made of high-quality die steel, which has been tempered and heat treated with stable performance and long service life.
2. Simplify the traditional production process, simplify and combine the two production processes of punching and pressing into one, saving energy consumption and improving efficiency.
3, can realize the accurate positioning of anchor disk size and effective use of cutting blade, greatly improve the production efficiency of anchor disk.
Dongfang Mould Factory specializes in the production of customized bolt tray stamping die, can be customized national standard, non-standard stamping die, to customize the drawing to sample.
